ABB ACS880-604

￭ Charging kits
The charging kit contains the main parts of the charging circuit, such as the charging switch
(with shaft, handle, terminal shrouds and a set of auxiliary contacts), fuses, connectors and
the charging controller. Note that the charging resistors or fiber optic cables are not included
in the kit and must be ordered separately.
IEC
Ordering codeQtyFrameBrake unit type ACS880-604-…
3AXD50000009537
1R8i0870-70630-50500-3
1R8i1300-70940-50750-3
22×R8i1730-71260-51000-3
22×R8i2600-71880-51510-3
33×R8i3900-72830-52260-3
44×R8i5200-73770-53010-3
55×R8i6500-74710-53770-3
UL
Ordering codeQtyFrameBrake unit type ACS880-604-…
3AXD50000009538
1R8i0870-70630-50500-3
1R8i1300-70940-50750-3
22×R8i1730-71260-51000-3
22×R8i2600-71880-51510-3
33×R8i3900-72830-52260-3
44×R8i5200-73770-53010-3
55×R8i6500-74710-53770-3
Kit contents:
ContentsOrdering code
Switch fuse (OS160GD04F) with terminal shrouds (OSS160GT1S/4); shaft (6 × 290 mm);
handle (OHB65J6); normally-closed auxiliary contacts (OA3G01, 2 pcs); 170M2676
fuses; charging controller
3AXD50000009537
Switch fuse (OS100GJ04FP) with terminal shrouds (OSS160GT1S/4); shaft (6 × 161 mm);
handle (OHB65J6); normally-closed auxiliary contacts (OA3G01, 2 pcs); FWJ30A fuses
and fuse holder modification parts; charging controller
3AXD50000009538
• Charging resistors are not included and must be ordered separately. See below.
• The charging controller connects to each inverter module by a pair of fiber optic cables.
The cables are not included and must be ordered separately.
88 Ordering information
