• VX = Kit specifically designed for the Rittal VX25 enclosure system. Many kits without
this designation are also used with the VX25 system.
Brake modules
The frame size of the brake modules is R8i. The delivery of a brake module includes these
items:
ContentsFrame sizeBrake module type
• brake module(s) (frame R8i) with speed-controlled cooling
fan(s)
•
internal du/dt filter (option +E205, included in the module
delivery as standard)
U
N
= 400 V (Range 380 … 415 V):
R8iACS880-604-0500-3
R8iACS880-604-0750-3
2×R8iACS880-604-1000-3
2×R8iACS880-604-1510-3
3×R8iACS880-604-2260-3
4×R8iACS880-604-3010-3
5×R8iACS880-604-3770-3
U
N
= 500 V (Range 380 … 500 V):
R8iACS880-604-0630-5
R8iACS880-604-0940-5
2×R8iACS880-604-1260-5
2×R8iACS880-604-1880-5
3×R8iACS880-604-2830-5
4×R8iACS880-604-3770-5
5×R8iACS880-604-4710-5
U
N
= 690 V (Range 525… 690 V):
R8iACS880-604-0870-7
R8iACS880-604-1300-7
2×R8iACS880-604-1730-7
2×R8iACS880-604-2600-7
3×R8iACS880-604-3900-7
4×R8iACS880-604-5200-7
5×R8iACS880-604-6500-7
Note: The following components are always required to construct a working unit and must
be ordered separately:
• BCU control unit kits, 1 kit/1 brake module
• Fiber optic cables
• 1 × Control circuit plug connector (3AUA0000059813)
• 1 × Control circuit plug connector (3AXD50000012975)
• Quick connectors, 1 kit/1 brake module (3AUA0000119227).
The other parts listed
• may be required by the application, or
• make the installation or use of the module easier.
Ordering information 79
