ABB ACS880-604

Input power (DC) connection
ACS880-104-xxxx-3 modules: 513…566 V DC. This is indicated in the type desig-
nation label as typical input voltage level 566 V DC.
Voltage (U
1
)
ACS880-104-xxxx-5 modules: 513…707 V DC. This is indicated in the type desig-
nation label as typical input voltage levels 566 / 679 / 707 V DC.
ACS880-104-xxxx-7 modules: 709…976 V DC. This is indicated in the type desig-
nation label as typical input voltage levels 742 / 849 / 976 (849 UL, CSA) V DC.
M12, maximum intrusion into module 20 mm (0.8”).Input terminals
Resistor connection
0…U
1
3-phase symmetrical.
Voltage (U
2
)
For ACS880-104-xxxx-3 modules: This is indicated in the type designation label
as typical output voltage level 3x 0…566 VDC.
For ACS880-104-xxxx-5 modules: This is indicated in the type designation label
as typical output voltage levels 3x 0…566 / 679 / 707 VDC.
For ACS880-104-xxxx-7 modules: This is indicated in the type designation label
as typical output voltage levels 3x 0…742 / 849 / 976 (849 UL, CSA) VDC.
300 m (984 ft)Maximum resistor cable
length
Busbars to quick connector: M12. Torque: 50 N·m (37 lbf·ft)Terminals (outgoing)
Busbars to support insulators: M8. Torque: 9 N·m (6.5 lbf·ft)
Cables to busbars: M12. Torque: 70 N·m (52 lbf·ft)
Cables to busbars: M12. Torque: 70 N·m (52 lbf·ft)Terminals (incoming)
Efficiency
Approximately 98% at nominal power levelEfficiency
Degree of protection
IP00Degree of protection
Ambient conditions
The unit is to be used in a heated indoor controlled environment.
Transportation in protect-
ive package
Storage in protective
package
Operation installed for
stationary use
--0…4000 m (13123 ft)*Altitude above sea level
Output derated above 1000
m (3281 ft). See section
Altitude derating.
*Neutral-grounded TN and
TT network systems, non-
corner-grounded IT net-
work systems. Corner-
grounded TN, TT and IT
network systems up to 600
V.
106 Technical data
