ABB ACS880-604

One R8i module in a 600 mm wide Rittal VX25 enclosure
with DC switch/disconnector
1
2
3
8
9
4
5
7
6
10
Cable entries for brake resistor and control
cables
6DC fuses1
Terminals for brake resistor cable connection7Brake chopper module2
DC switch/disconnector behind the plate8Brake chopper module cooling fan3
Charging switch with fuses behind the plate9Brake resistor fuses4
Charging resistors behind the plate10BCU-02 brake control unit5
32 Cabinet construction
4
