ABB ACS880-604

Kit ordering codeKit codeInstruction codeParts to be installed#
Common parts:1
--3AXD50000336340
• Baying parts
--3AXD50000336104
• PE busbar
--3AXD50000336692
• Divider panel
3AXD50000333387A-468-X-001-VX3AXD50000333639
• DC busbars
DC connection 1 of 2 (busbars from DC bus to DC fuses and flanges from DC fuses to brake chopper
module)
2A
3AXD50000489084A-6-8-262-VX3AXD50000493555
• Mounting plate as-
sembly with DC bus-
bars
3AXD50000489091A-468-8-216-VX3AXD50000493265
• DC connection bus-
bars
3AXD50000016896A-6-8-2633AXD50000016945
• DC connection
flanges
DC connection 1 of 2 (from DC bus to DC fuses) with DC switch and charging2B
3AXD50000504596A-6-8-217-VX3AXD50000493395
• DC switch/charging
mechanics
3AXD50000337453A-46-8-207-VX3AXD50000345458
• Busbars
Quick connector, outgoing resistor busbars (cable connection):3
3AUA00000119227A-468-8-1003AUA0000118667
• Quick connector
3AXD50000489213A-6-8-147-VX3AXD50000493388
• Outgoing resistor bus-
bars and shrouds
DC connection 2 of 2 (from DC bus to output DC fuses to resistor connection terminals):4
3AXD50000489107A-6-8-215-VX3AXD50000493357
• Incoming resistor bus-
bars
Brake module installation and brake resistor cable entries5
3AXD50000489060A-6-8-330-VX3AXD50000492145
• Mounting plates
3AXD50000004385A-468-8-4413AXD50000004817
• Cable entry kits
3AXD50000489077A-6-8-400-VX3AXD50000493579Side support6
3AXD50000504725A-6-8-358-VX3AXD50000492947Shroud7
---Brake chopper module8
