Type designation of the module
Type designation describes the composition of the module in short. The complete designation
code is divided in subcodes:
• The first digits form the basic code. It describes the basic construction of the module.
The fields in the basic code are separated by hyphens.
• The plus codes follow the basic code. Each plus code starts with an identifying letter
(common for the whole product series), followed by descriptive digits. The plus codes
are separated by plus signs.
The subcodes are described below.
DESCRIPTIONCODE
Basic codes
Product seriesACS880
Construction: Inverter, supply, converter or brake module.104
Size
Refer to the ratings table in the technical data.xxxxx
Voltage range
513…566 V DC. This is indicated in the type designation label as typical input voltage level
566 V DC.
3
513…707 V DC. This is indicated in the type designation label as typical input voltage levels
566/679/707 V DC.
5
709…976 V DC. This is indicated in the type designation label as typical input voltage levels
742/849/976 V DC (849 V DC for UL/CSA).
7
Option codes (plus codes)
Internal heating elementC183
Direct-on-line (DOL) cooling fanC188
Internal du/dt filtering. Included in the module delivery as standard.
E205
115 V auxiliary voltage supplyG304
Extended warranty 24/30P904
Extended warranty 36/42P909
26 Operation principle and hardware description
