ControlMaster CM15 and CMF160
Universal process indicator
1
/8 DIN Appendix B – Error Codes
98 IM/CM/I–EN Rev. P
B.2 Profile Error Codes
152 Alarm Ack State 6
153 Alarm State 7
154 Alarm Ack State 7
155 Alarm State 8
156 Alarm Ack State 8
167 Analog O/P Loop break A1
168 Analog O/P Loop break B1
177 Delay Timer State 1
178 Delay Timer State 2
189 Toggle Signal
190 Edge Signal
Error
Code
Error Description
Error
Code
Error Description
1 Jump Target Invalid
Current active program is
configured to jump
to another program, upon the
completion of this action it is
found that the next program
has been configured
incorrectly.
2 Retort Rampback Invalid
Retort Rampback value is a
negative number and must
be changed.
3 Retort Previous Invalid
There is no previous segment
therefore the program is
unable to jump back to the
last ramp rate.
4 PV Invalid
The Process Variable has
failed.
5 Local Setpoint has Failed
The Local setpoint has
become invalid. This may be
that it has travelled outside of
its permissible limits.
9 Validation
The current program is
configured incorrectly and
therefore judged invalid by
the software validation.
Error
Code
Error Description
