ABB ControlMaster CM15 User Manual

ControlMaster CM15 and CMF160
Universal process indicator
1
/8 DIN 4 Installation
10 IM/CM/I–EN Rev. P
4.2 Dimensions
4.2.1 CM15 Indicator
Dimensions in mm (in.)
Fig. 4.3 ControlMaster CM15 Dimensions
Panel Cut-out
Dimensions
97 (3.8)
50
(2.0)
120 (4.8)
140 (5.5)
44.8
(1.7)
20 (0.8)
92
(3.6)
14 (0.55)
30 (1.18)
45
(1.8)
+0.8
–0
(+0.03
–0)
+0.6
–0
(+0.02
–0)
Cable Gland Kit (Optional)
