ControlMaster CM15 and CMF160
Universal process indicator
1
/8 DIN Appendix A – Digital and Analog Sources
94 IM/CM/I–EN Rev. P
Appendix A – Digital and Analog Sources
A.1 Digital Sources
Note. Numbers in brackets indicate additional parameters, for example, 'Alarm 1 (8) Ack. State indicates that 8 Alarm Ack.
State parameters are available.
Source Name Description [Comment]
Alarm 1 (8) Ack. State
Acknowledged alarm = 0
Unacknowledged alarm = 1
Alarm 1 (8) State Alarm state
Anlg IP 1 (2) Fail (CM15)
Anlg IP 1 (4) Fail (CMF160)
Analog input failure (active when the
signal detected at the analog input is
outside the fault detect level specified
during configuration).
AO1 (2) Loop Break Analog output
Delay Timer 1 (2) Delay timer state
IP 1 (2) Digital State (CM15)
IP 1 (4) Digital State (CMF160)
Input 1 (2) digital state
Linearizer 1 (2) Fail Custom linearizer failure
Logic Equation 1 (8) Logic equation result
Math Block 1 (8) Fail Maths failure
RTA 1 (2) State Real time alarm state
Softkey Toggle
Front panel soft key toggles the
source’s state.
Softkey Edge
Front panel soft key sets the source
active on key press.
T1 (2) Int Pulse
Totalizer intermediate pulse. Active for
1 second when the intermediate
count is reached.
Source Name Description [Comment]
