4.2.2 CMF160 Indicator Panel-, Pipe- and Wall-mount Dimensions
Dimensions in mm (in.)
*To DIN43700
**150 mm (6 in.) if (optional) cable glands fitted
Fig. 4.4 ControlMaster CMF160 Panel-mount Option
92
(3.6)
35
(1.4)
213 (8.38)
194
(7.64)
Mounting Panel – Maximum
Thickness 6 (0.236)
 40 (1.57)**
 40
(1.57)
(7.32 )
+0.04
–0
+1.1
–0
186
(7.32 )
+0.04
–0
+1.1
–0
186
