ABB ControlMaster CM15 User Manual

ControlMaster CM15 and CMF160
Universal process indicator
1
/8 DIN 4 Installation
28 IM/CM/I–EN Rev. P
4.5.7 Digital Input / Output, Relays and Analog Output Connections – CMF160 Indicator
Note. Digital input and open collector digital output connections are shown in Fig. 4.19 – see page 94 for
Digital Input / Output type options.
Fig. 4.20 Digital Input / Output, Relays and Analog Output Connections – CMF160 Indicator
+
–
N/O
Relays (1 to 4)
COM
N/C
Analog Outputs (1 to 4)
Load
Load
Chart Recorder
L
N
L
750 
Max.
Relays (5 and 6)
Digital Input (24 Volt)
Load
COM
N/C
N
L
INT +24 V
DIO 1 to 6
DIO COM
INT +24 V (100 mA Max.)
Digital Input (Voltage-free))
DIO 1 to 6
DIO COM
DIO 1 to 6
Load
