ControlMaster CM15 and CMF160
Universal process indicator
1
/8 DIN 10 Specification
86 IM/CM/I–EN Rev. P
10 Specification
Operation
Display
Color,
1
/4 VGA TFT, liquid crystal display (LCD) with built-in backlight
Language
English, German, French, Italian and Spanish
Operator keypad
CM15: 4 tactile membrane keys
CMF160: 6 tactile membrane keys
Security
Password protection
Basic / Advanced – user-assigned (not factory-set)
Standard functions
Templates
Process alarms
Number
8
Types
High / Low process and High / Low latch
Source
Fully configurable
(for example – PV, Analog input, Math block inbuilt)
Hysteresis
Level and time
Alarm enable
Enable / Disable individual alarms via a digital signal
Acknowledgement
Via front panel keys or digital signals
Real-time alarms *
*Functionality level 'Standard' and above only
Base Single PV indication
Single PV indication + totalizer
Counter
Single PV indication + level
Dual Dual PV indication
Dual PV indication + totalizer
Dual counter
Dual PV indication + level
Number 2
Programmable Time
Day
Duration
