ABB ControlMaster CM15 User Manual

ControlMaster CM15 and CMF160
Universal process indicator
1
/8 DIN 4 Installation
12 IM/CM/I–EN Rev. P
Dimensions in mm (in.)
Fig. 4.5 ControlMaster CMF160 Pipe-mount Option
66
(2.6)
213 (8.38)
194
(7.64)
Cable Gland Kit (Optional)
98
(3.85)
170 (6.70)
Pipe Diameters:
Max. 62 (2.44) / min.
45 (1.77)
Pipe-mount Kit
(Optional – CM40/0700)
Vertical Configuration
Horizontal Configuration
Pipe-mount Kit
(Optional – CM40/0700)

ABB ControlMaster CM15 Specifications

General

Brand	ABB
Model	ControlMaster CM15
Category	Controller
Language	English
