ControlMaster CM15 and CMF160
Universal process indicator
1
/8 DIN 4 Installation
IM/CM/I–EN Rev. P 13
Dimensions in mm (in.)
Fig. 4.6 ControlMaster CMF160 Wall-mount Option
Cable Gland Kit (Optional)
214 (8.42)
62 (2.44)
66 (2.40)
200 (7.87)
Fixing Centers
Fixing
centers
Ø6.4 (0.25)
