ControlMaster CM15 and CMF160
Universal process indicator
1
/8 DIN 4 Installation
14 IM/CM/I–EN Rev. P
Dimensions in mm (in.)
Fig. 4.7 ControlMaster CMF160 Weathershield (CM40/0702) – Pipe- and Wall-mount (CM40/0700) Options
240 (9.45)
240
(9.45)
175 (6.89)
Wall-mount Entries
Pipe-mount Entries
