ControlMaster CM15 and CMF160
Universal process indicator
1
/8 DIN 4 Installation
IM/CM/I–EN Rev. P 23
Fig. 4.15 ControlMaster CMF160 Terminal Connections
COMMS
OUT 1 OUT 2
RELAY 1 RELAY 2 RELAY 3 RELAY 4
NL
INT
+24V
DIO1 DIO2 DIO3 DIO4 DIO5 DIO6
DIO COM
N/O
COM
N/C
N/O
COM
N/C
N/O
COM
N/C
N/O
COM
N/C
I/O MODULE 3
Input 1 Input 2 Tx PSU
SK2
12
+–+–
I/O MODULE 3
345
Digital I/O
Connections
Comms.
Connections
Analog Output
Connections 1 and
2 (Standard)
Relay Connections
1 to 4 (Standard)
Mains Supply 100 V to 240 V
AC ±10 % (90 V min. to 264
V max.) 50 / 60 Hz
Analog Input Module 1
Terminal Connections
Fuse 3.15 A Type T
100 to 240 V, 50/60 Hz
Analog Outputs
3 and 4 (Optional)
Relay Connections
5 and 6 (Optional)
