ABB ControlMaster CM15 User Manual

ControlMaster CM15 and CMF160
Universal process indicator
1
/8 DIN 7 Advanced Level
58 IM/CM/I–EN Rev. P
Digital Mode
The count rate setting determines the scaling of the digital input pulses.
For example, with a Count Rate = 100 totalizer units / pulse, 5 digital input pulses increment the totalizer from 0 to 500 in
100 unit steps:
500
400
300
200
100
0
1 Minute
Units
Totalizer Value
Input Signal
t
t
On
Off
1 Minute
