ControlMaster CM15 and CMF160
Universal process indicator
1
/8 DIN 7 Advanced Level
60 IM/CM/I–EN Rev. P
Pulse Mode
For example:
Pulse / Unit = 50, Pulse Units = l, Totalizer required to increment in m
3
.
Volume unit conversion: 1 l = 0.001 m
3
.
Count Rate =
Volume unit conversion
Pulse / Unit
Count Rate =
0.001
= 0.00002 m
3
/pulse
50
