ControlMaster CM15 and CMF160
Universal process indicator
1
/8 DIN 7 Advanced Level
62 IM/CM/I–EN Rev. P
…Functions / Logic Equations
Equation Number Selects the logic equation to be configured.
Operand 1 (8) See Appendix A, page 94 for description of sources.
Invert 1 (8) Logically inverts (applies NOT function to) the digital signal.
For example, if the digital signal assigned to the operand has a state of '1' it is inverted to a state
of '0' before being applied to the equation.
Operator1 (7) Selects the Operator type: OR, AND, NOR, NAND, EXOR, END.
Select END if no more elements are required.
Math Blocks Up to 8 math blocks can be configured. Each block can be configured as 1 of 6 different types
(see Block Type below). The resulting analog value can be used as a source for other function
blocks, for example, Process Variable in the Custom Config parameter – see page 37.
Math Block Number The math block number (1 to 8).
Block Type Selects the type of math block required.
