ControlMaster CM15 and CMF160
Universal process indicator
1
/8 DIN 7 Advanced Level
74 IM/CM/I–EN Rev. P
…Functions / …Bank Control
Bank Size Select the number of stages (pumps) required for the application from 2 to 6 or Off.
Off disables the Bank Control functionality.
Control Source Select the analog signal to act as the control signal for the bank control.
This is normally the Process Variable (PV) for most pump control applications.
Stage 1 (6)
Off Trip Select the Control Source value (PV) at which the output (pump) is turned off.
On Trip Select the Control Source value (PV) at which the output (pump) is turned on.
Output Select the initial output (relay or digital output) that the output is assigned to by
default (for example, when FIFO or Rotate mode is not in operation).
Schedule Select the wear levelling schedule required:
Off – the output is not controlled by the bank schedule.
The state of the output is controlled entirely by its associated trip points.
FIFO – the output is controlled according to the FIFO schedule mode.
Rotate – the output is controlled according to the Rotate schedule mode.
