ABB ControlMaster CM15 User Manual

ControlMaster CM15 and CMF160
Universal process indicator
1
/8 DIN 10 Specification
IM/CM/I–EN Rev. P 89
Inputs
Thermocouple Maximum range °C (°F) Accuracy (% of reading)
B –18 to 1800
(0 to 3270)
0.1 % or ±2 °C (3.6 °F)
(above 200 °C [392 °F]) *
E –100 to 900
(–140 to 1650)
0.1 % or ±0.5 °C (0.9 °F)
J –100 to 900
(–140 to 1650)
0.1 % or ±0.5 °C (0.9 °F)
K –100 to 1300
(–140 to 2350)
0.1 % or ±0.5 °C (0.9 °F)
L –100 to 900
(–140 to 1650)
0.1 % or ±1.5 °C (2.7 °F)
N –200 to 1300
(–325 to 2350)
0.1 % or ±0.5 °C (0.9 °F)
R –18 to 1700
(0 to 3000)
0.1 % or ±1 °C (1.8 °F)
(above 300 °C [540 °F]) *
S –18 to 1700
(0 to 3000)
0.1 % or ±1 °C (1.8 °F)
(above 200 °C [392 °F]) *
T –250 to 300
(–400 to 550)
0.1 % or ±0.5 °C (0.9 °F)
(above –150 °C [–238 °F]) *
* Accuracy is not guaranteed at temperatures below this value
RTD Maximum range °C (°F) Accuracy (% of reading)
Pt100 –200 to 600
(–325 to 1100)
0.1 % or ±0.5 °C (0.9 °F)
Linear inputs Standard analog input Accuracy (% of reading)
Millivolts
Milliamps
Volts
Resistance (low)
Resistance (high)
0 to 150 mV
0 to 45 mA
0 to 25 V
0 to 550 
0 to 10 k
0.1 % or ±20 µV
0.2 % or ±4 µA
0.2 % or ±20 mV
0.2 % or ±0.1
0.1 % or ±10
Sample Interval 125 ms per sample
Digital inputs
Type Volt-free or 24 V
Minimum pulse
duration
Single input configured – 250 ms
Both inputs configured as analog or digital – 500 ms
Volt-free Contact open > 10 M / contact closed < 100 k
Frequency input*
Frequency range
1-signal
0-signal
0 to 6000 Hz
15 to 30 V
–3 to 5 V
* For use with devices with open collector outputs
