Parameters
202 2CDC508198D0211 Rev. A | AC/S 1.x.1
Object name
Data type
Split unit, On/Off DPT 1.001
The module has this output socket if the
Yes
option is selected for the
Split unit
parameter.
Outputs the operating status of the split unit.
Signal value:
0 = Off
1 = On
Split unit, fan speed
DPT 5.001
The module has this output socket if the
Yes
option is selected for the
Split unit
parameter.
Outputs the fan speed in the split unit.
Signal value:
0…100 %
Split unit, status DPT 20.105
The module has this output socket if the Yes option is selected for the Split unit parameter.
Outputs the status of the split unit.
Signal value:
0 = Auto
1 = Heat
2 = Morning Warmup
3 = Cool
4 = Night Purge
5 = Precool
6 = Off
7 = Test
8 = Emergency Heat
9 = Fan only
0A = Free Cool
0B = Ice
0C = Maximum Heat Mode
0D = Economic Heat/Cool Mode
0E = Dehumidification
0F = Calibration Mode
10 = Emergency Cool Mode
11 = Emergency Steam Mode
14 = No Dem
