Parameters
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 201
Object name
Data type
Floor heating, valve DPT 1.001
DPT 5.001
The data point type for the output socket is dependent on the settings in the module.
• If the On/Off option is selected for the Floor heating
parameter:
DPT 1.001
Signal value: 0 = Off, 1 = On
• If the 0…100 % option is selected for the Floor heating
parameter:
DPT 5.001
Signal value: 0…100 %
Outputs the position of the floor heating valve.
Floor temperature sensor
DPT 9.001
The module has this output socket if the On/Off option or the 0…100 % option is selected for the Floor heating parameter and
the Yes option is selected for the Floor temperature sensor parameter.
Outputs the floor temperature.
Signal value: -273...670760 °C
Cooling ceiling, valve
DPT 1.001
DPT 5.001
The data point type for the output socket is dependent on the settings in the module.
• If the On/Off option is selected for the Cooling ceiling parameter:
DPT 1.001
Signal value: 0 = Off, 1 = On
• If the 0…100 % option is selected for the Cooling ceiling
parameter:
DPT 5.001
Signal value: 0…100 %
Outputs the position of the cooling ceiling valve.
Cooling ceiling, dew point alarm sensor
DPT 1.001
The module has this output socket if the
On/Off
option or the
0…100 %
option is selected for the
Cooling ceiling
parameter
and the Yes option is selected for the Cooling ceiling, dew point alarm sensor parameter.
Outputs the signal value from the dew point sensor in the cooling ceiling.
Signal value: 0 = Off
1 = On
