Page #211 background image
ABB i-bus
®
KNX
Parameters
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 211
Object function
Name (can be changed
separately)
Data type
Flags
Input: Fan coil unit, valve cooling
Room
1 byte
DPT 5.001
C, W, T, U
The module has this group object if the 2-pipe cooling option or the 4-pipe heating + cooling option is selected for the Fan coil
unit parameter.
Input for the valve position (control value) on the fan coil unit for cooling.
Telegram value:
0…100%
Input: Fan coil unit, valve Room 1 byte
DPT 5.001
C, W, T, U
The module has this group object if the 2-pipe heating/cooling option is selected for the Fan coil unit parameter.
Input for the valve position (control value) on the fan coil unit. This is for either heating or cooling depending on the
heating/cooling operating type.
Telegram value: 0…100%
Input: Fan coil unit, fan speed
Room
1 byte
DPT 5.001
C, W, T, U
The module has this group object if any option except None is selected for the Fan coil unit parameter and the Display option
is selected for the Fan coil unit, fan speed parameter.
Input for the fan speed on the fan coil unit.
Telegram value:
0…100%
Input: Fan coil unit, fan manual Room 1 bit
DPT 1.011
C, W, T, U
The module has this group object if any option except
None
is selected for the
Fan coil unit
parameter and the
Display
option
is selected for the Fan coil unit, fan speed parameter.
Input for the connection of the status from the room thermostat as to whether the current fan speed has been adjusted
manually by a user or it was calculated automatically by the room thermostat.
Telegram value:
0 = Automatic
1 = Manual
