Parameters
222 2CDC508198D0211 Rev. A | AC/S 1.x.1
Object name
Object type
Unit
COV send
condition
Room: Fan coil unit, fan manual
Binary value
-
-
The module has this BACnet output object if any option except None is selected for the Fan coil unit parameter.
Outputs whether the current fan speed has been adjusted manually by a user or it was calculated automatically by the room
thermostat.
Signal value: 0 = Automatic
1 = Manual
Room: Fan coil unit, additional-stage heating Binary value
Analog value
-
% (98)
-
1.0
Outputs the status of the additional-stage heating
The object type for the object is dependent on the settings in the module:
• If any option except None is selected for the Fan coil unit parameter and the On/Off option is selected for the
Fan coil unit,
additional-stage heating parameter:
Object type binary value
Unit –
Send condition –
Signal value 0 = Off, 1 = On
• If any option except None is selected for the Fan coil unit parameter and the 0…100 % option is selected for the
Fan coil
unit, additional-stage heating parameter:
Object type analog value
Unit % (98)
Send condition 1.0
Signal value 0…100 %
Room: Fan coil unit, fresh air damper
Binary value
Analog value
-
% (98)
-
1.0
Outputs the position of the fresh air damper.
The object type for the object is dependent on the settings in the module:
• If any option except None is selected for the Fan coil unit parameter and the Open/Closed option is selected for the
Fan
coil unit, fresh air damper parameter:
Object type binary value
Unit –
Send condition –
Signal value 0 = Closed, 1 = Open
• If any option except None is selected for the Fan coil unit parameter and the 0…100 % option is selected for the
Fan coil
unit, fresh air damper parameter:
Object type analog value
Unit % (98)
Send condition 1.0
Signal value 0…100 %
