Parameters
268 2CDC508198D0211 Rev. A | AC/S 1.x.1
Object name
Data type
Pump B override disable/enable DPT 1.003
The module has this output socket if the
Yes
option is selected for the
Double pump
parameter and the
Yes
option is selected
for the Override by WebUI parameter.
Outputs whether the heating distribution circuit's second pump is overridden.
Signal value: 0 = Disabled
1 = Enabled
Pump B override value
DPT 1.001
The module has this output socket if the Yes option is selected for the Double pump parameter and the Yes option is selected
for the Override by WebUI parameter.
Outputs the state with which the heating distribution circuit's second pump is overridden if the pump override is active.
Signal value:
0 = Off
1 = On
Supply setpoint temperature
DPT 9.001
The module has this output socket if the
Yes
option is selected for the
Supply temperature control
parameter.
Outputs the current supply setpoint temperature as is sent by the module to the heating distribution circuit controller via the
related group object. The supply setpoint temperature output here is, depending on the setting, either calculated by this
module based on the outside temperature, or specified via an ASM input socket or BACnet and also takes into account any
possible override of the supply setpoint temperature via the web user interface.
Signal value:
-273...670760 °C
Supply setpoint temperature External specification
DPT 9.001
This module has this output socket if the
Yes
option is selected for the
Supply temperature control
parameter and the
BACnet
input object option is selected for the Supply setpoint temperature source parameter.
Outputs the supply setpoint temperature specified via the BACnet object. This status does not take into account any possible
override of the supply setpoint temperature via the web user interface.
Signal value: -273...670760 °C
