ABB i-bus KNX AC/S 1.x.1 Series User Manual

ABB i-bus
®
KNX
Parameters
280 2CDC508198D0211 Rev. A | AC/S 1.x.1
Object name
Object type
Unit
COV send
condition
Heating distribution circuit: Max. room setpoint temperature
Analog value
°C (62)
1.0
This module has this BACnet output object if the Yes option is selected for the Supply temperature control parameter, the
Calculated weather compensated option is selected for the Supply setpoint temperature source parameter and the Based on
the current room setpoint temperatures option is selected for the Economy mode parameter.
Outputs the highest room setpoint temperature that is present on the ASM input socket and that is used by the Economy mode
function.
Signal value: -273...670760 °C
Heating distribution circuit: Control On/Off
Binary value
-
-
The module has this BACnet output object in the following conditions:
• If the Yes option is selected for the Supply temperature control parameter and the Yes option is selected for the
Enable
heating distribution circuit control based on ASM input socket parameter.
• If the Yes option is selected for the Switch off if no room demand
parameter.
Outputs the status (Off/On) of the control that is sent to the heating distribution circuit controller via the related group object.
The state is dependent on the Enable heating distribution circuit control based on ASM input socket and Switch off if no room
demand functions as well as any override via the web user interface.
Signal value: 0 = Off
1 = On
Heating distribution circuit: Room involvement Analog value °C (62) 1.0
The module has this BACnet output object if the
Yes
option is selected for the
Supply temperature control
parameter, the
Calculated weather compensated option is selected for the Supply setpoint temperature source parameter and the Yes option
is selected for the Room involvement parameter.
Outputs of current value by which the supply setpoint temperature is increased or reduced by the Room involvement function.
Signal value: -273...670760 °C
