Parameters
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 327
Object name
Object type
Unit
COV send
condition
Heat generator: Control On/Off override disable/enable
Binary value
-
-
The module has this BACnet output object in the following conditions:
• If the Yes option is selected for the Supply temperature control parameter and the Yes option is selected for the
Enable
heat generator based on ASM input socket parameter.
• If the Yes option is selected for the Switch off if no room demand
parameter.
Outputs whether heat generator on/off has been overridden via the web user interface.
Signal value:
0 = Not overridden
1 = Overridden
Heat generator: Heat generator operating status
Binary value
-
-
The module has this BACnet output object if the Yes option is selected for the Show operating status parameter.
Outputs the operating status (Off/On) provided by the heat generator. Due to the control integrated into the heat generator,
this status may differ from the operating status specified by this module.
Signal value:
0 = Off
1 = On
Heat generator: Heat generator failure status
Binary value
-
-
The module has this BACnet output object if the
Yes
option is selected for the
Show fault status
parameter.
Outputs the fault status provided by the heat generator.
Signal value: 0 = Off
1 = On
Heat generator: Room control values Analog value % (98) 1.0
The module has this BACnet output object in the following conditions:
• If the Yes option is selected for the Supply temperature control
parameter, the Calculated weather compensated option is
selected for the Supply setpoint temperature source parameter and the Yes option is selected for the Room involvement
parameter.
• If the Yes option is selected for the Switch off if no room demand
parameter.
Outputs the highest room setpoint temperature that is present on the ASM input socket and that is used by the Economy mode
and Switch off if no room demand functions.
Signal value: 0…100 %
