- 22 -
000888AG
2 - Characteristics
O
verall dimensions REACT2-3.6/5.0-TL-OUTD
The overall dimensions are expressed in millimetres and include the
wall installation bracket.
490mm
490mm
985mm
229mm
740mm
740mm
490mm
490mm
490mm
1480mm
229mm
740mm
490mm
490mm
490mm
1975mm
229mm
490mm
