ABB REACT 2 Series - Efficiency Curves

- 30 -
000889AG
2 - Characteristics
Efficiency curves
The equipment was designed considering current energy conservation
standards, to avoid waste and unnecessary leakage.
Graphs of the HI¿FLHQF\FXUYHVRIDOOmodels of inverter described in this
manual are shown below.
The HI¿FLHQF\FXUYHVDUHOLQNHGWRWHFKQLFDOSDUDPHWHUVWKDWDUHFRQWLQXDOO\EHLQJGHYHORSHG
and improved and should therefore be considered approximate.
REACT2-UNO-3.6-TL
REACT2-UNO-5.0-TL
84
86
88
90
92
94
96
98
100
Eciency, %
% of Rated Output Power
470 Vdc
390 Vdc
200 Vdc
0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100%
(I¿FLHQF\FXUYHV
84
86
88
90
92
94
96
98
100
Eciency, %
% of Rated Output Power
470 Vdc
390 Vdc
200 Vdc
0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100%
(I¿FLHQF\FXUYHV
