ABB REACT 2 Series - Dimensions Bracket REACT2-BATT

- 23 -
000888AG
2 - Characteristics
D imensions bracket REACT2-BATT
The dimensions of the wall mounting bracket are expressed in mm
39
325
139.5
503.5
40
102.5
22
22
290
9
15
15
9
68
50.5
30.5 27
4
22
68
