ABB REACT 2 Series - Topographic Diagram of the Equipment

- 43 -
000892AG
2 - Characteristics
T opographic diagram of the equipment
IN1.1(+)
IN1.2(+)
IN1.1(-)
IN1.2(-)
IN2.1(+)
IN2.2(+)
IN2.1(-)
IN2.2(-)
MPPT 1
(DC/DC)
MPPT 2
(DC/DC)
Bulk caps
Inverter
(DC/AC)
Grid parallel
relay
Line
filter
L
N
PE
Residual current
detection
Remote control
+ R
- R
Output 1
N.C
N.O
C
Output 2
N.C
N.O
C
L
N
AC
Output
AC
Backup
Output
REACT2-UNO
Charger/
Discharger
(DC/DC)
REACT2-BATT (Opt.)
Switch
+ T/R
- T/R
RTN
+ T/R
- T/R
RTN
WIFI LAN1 LAN2
RS485
PC
RS485
METER
+ T/R
- T/R
RTN
RS485
LOGGER
Protection
Battery
pack
DC/DC
DSP
contr.
DC/AC
DSP
contr.
μP
Control circuit
BMS DSP
Charger/
Discharger
(DC/DC)
REACT2-BATT (Opt.)
Protection
Battery
pack
BMS DSP
