- 53 -
000895AG
4 - Lifting and transport
Lifting
ABB usually stores and protects individual components by suitable means
to make their transport and subsequent handling easier. Nonetheless, as
a rule, it is necessary to turn to the experience of specialised staff to take
charge of loading and unloading components.
Where indicated and/or available, eyebolts or handles, which can be
used as anchorage points, are inserted and/or can be inserted.
The number of required operators necessary to lift the equipment must be in accordance to
local regulations relating lifting limits per operator.
The ropes and means used for lifting must be suitable for bearing the weight of the equipment.
Do not lift several units or parts of the equipment at the same time,
unless otherwise indicated.
E
quipment weight
5LVNRILQMXU\GXHWRWKHZHLJKWRIWKHHTXLSPHQW7DNHFDUHGXULQJOLIWLQJDQGWUDQVSRUW
Device Weight (kg/lb) Lifting points
REACT2-UNO-3.6/5.0-TL < 22 kg
4 (suggested in case of 2 operators)
REACT2-BATT 50 kg
4 (suggested in case of 2 operators)
