ABB REACT 2 Series - Characteristics and technical data

- 22 -
000888AG
2 - Characteristics
Characteristics and technical data
System components of REACT2 photovoltaic
system with storage
REACT2-3.6-TL-OUTD REACT2-5.0-TL-OUTD
Inverter unit REACT2-UNO-3.6-TL REACT2-UNO-5.0-TL
Battery unit REACT2-BATT
Energy meter REACT-MTR-1PH; ABB B21-212; ABB B23-212; ABB B24-212
Inverter REACT2-UNO-3.6-TL REACT2-UNO-5.0-TL
PV port
Absolute maximum DC input voltage (Vdc, max) 575 V
Start-up DC input voltage (Vstart) 200 V (adj. 120...350 V)
Operating DC input voltage range (Vdcmin...Vdcmax) 0.7 x Vstart ...575 V (min 90 V)
Rated DC input voltage (Vdcr) 390 V
Rated DC input power (Pdcr) 5000 W 6000 W
Number of Independent MPPT 2
Maximum DC input power for each MPPT (PMPPTmax)
2500W Linear derating
>9903379@
3000W Linear derating
>9903379@
'&LQSXWYROWDJHUDQJHZLWKSDUDOOHOFRQ¿JXUDWLRQRI0337DW
Pacr, not operative battery
160 V…480 V 195 V…480 V
Maximum DC input current (Idc max) / for each MPPT
(IMPPTmax)
24 A / 12 A 27 A / 13.5 A
Maximum input short circuit current for each MPPT (Iscmax) 15 A
Maximum Return current (AC side vs DC side) Negligible in normal operating conditions
(6)
Number of DC input connection pairs for each MPPT 2
DC connection type 4XLFN¿W39FRQQHFWRU
(1)
PV port protection
Reverse polarity protection Yes, from current limited source
Input overvoltage protection for each MPPT - varistor Yes
Photovoltaic array isolation control According to local standard
DC switch rating for each MPPT 25 A / 575 V
Output AC port
AC grid connection type Single-phase
5DWHG$&SRZHU3DFU#FRVij  3600 W 5000 W
(2)
0D[LPXP$&RXWSXWSRZHU3DFPD[#FRVij  3600 W 5000 W
(2)
Maximum apparent power (Smax) 3600 VA 5000 VA
(2)
Rated AC grid voltage (Vac,r) 230 V
AC voltage range 180...264 V
(3)
Maximum AC output current (Iac,max) 16 A 22 A
Contributory fault current 16A 22A
Inrush current Negligible
Rated output frequency (fr) 50 Hz / 60 Hz
Output frequency range (fmin...fmax) 45...55 Hz / 55…65 Hz
(4)
Nominal power factor and adjustable range > 0.995, adj. ± 0.1 - 1 (over/under exited)
Total current harmonic distortion <3%
AC connections type Panel connector
Output AC port protection
Anti-islanding protection According to local standard
Maximum external AC overcurrent protection 20 A 25 A
Output overvoltage protection - varistor 2 (L - N / L - PE)
Backup output port
AC grid connection type Single-phase
Maximum apparent power (Smax) 3000 VA
Rated AC grid Voltage (Vacr) 230 V
AC Voltage range 180...264 V
(3)
Maximum AC output current (Iac max) 13 A
Rated output frequency (fr) 50 Hz / 60 Hz
Output frequency range (fmin...fmax) 45...55 Hz / 55…65 Hz
(4)
AC connections type Screw terminal block
