2 - Characteristics
Inverter REACT2-UNO-3.6-TL REACT2-UNO-5.0-TL
Backup output protection
Maximum external AC overcurrent protection 16 A
Output overvoltage protection - varistor 2 (L-N/L-PE)
Input AC port
AC voltage range 230 V
Maximum AC input current (Iac max) 16 A 22 A
Inrush current Negligible
Rated output frequency (fr) 50 Hz / 60 Hz
Battery port
Operating DC input voltage range (Vdcmin...Vdcmax) 170 V…575 V
Maximum DC charge current (Idc,max charge) 13.5 A 13.5 A
Rated AC grid Voltage (Vacr) 10 A 10 A
Operating performance
0D[LPXPHI¿FLHQF\ȘPD[ 97.1%
:HLJKWHGHI¿FLHQF\(852&(& 96.3% / - 96.6% / -
Embedded communication
Embedded physical interface Wireless
(5)
, 2 x Ethernet, RS485
Embedded communication protocols
Modbus TCP (SunSpec), Modbus RTU (Sunspec),
ABB-free@home
®
Datalogger data retention 30 days
Remote monitoring Mobile app
Local monitoring Web server user interface
Environmental
Ambient temperature range
-20...+55°C with
derating above 50°C
-20...+55°C with
derating above 45°C
Relative humidity 4…100 % condensing
Acoustic noise emission level < 50 dB (A) @ 1 m
Maximum operating altitude without derating 2000 m / 6560 ft
(QYLURQPHQWDO SROOXWLRQ GHJUHH FODVVL¿FDWLRQ IRU H[WHUQDO
environments
3
Environmental class Outdoor
Suitable for wet location Yes
Physical
Environmental protection rating IP65
Cooling Natural
Dimension (H x W x D) 740 mm x 490 mm x 229 mm
Weight < 22 kg
Mounting system Wall bracket
Overvoltage rating as per IEC 62109-1 II (DC input) III (AC output)
Safety
Safety class I
Insulation level Transformerless
Marking CE
Safety and EMC Standards
IEC/EN 62109-1, IEC/EN 62109-2, EN 61000-6-2,
EN 61000-6-3, EN 61000-3-2, EN 61000-3-3,
EN61000-3-11, EN61000-3-12
Grid standard (check your sales channel for availability)
CEI 0-21, DIN V VDE V 0126-1-1, VDE-AR-N 4105,
G83/2, G59/3, RD 413,
AS/NZS 4777.2,C10/11, IEC 61727, IEC 62116
Other features
Load manager Yes, with two integrated relays
AC backup output, off grid Yes
Battery charge from AC Yes, it can be enabled
AC-coupled Yes
