- 22 -
000888AG
2 - Characteristics
Battery Unit REACT2 - BATT
Modules manufacturer Samsung
Battery type Li-Ion
Total energy 4 kWh
Maximum battery voltage (Vdc max) 575 V
Battery voltage range (Vdc operating range) 170...575 V
Maximum DC charge current (Idc max charge) 4.5 A for each battery installed
Maximum DC discharge current (Idc,max
discharge)
5.6 A for each battery installed
Deep of discharge (DoD) 95%
N° of battery unit that can be connected to the
REACT2-UNO inverter
1, 2, 3
Charge power
1.6 kW (1xREACT2-BATT),
3.2 kW (2xREACT2-BATT),
4.8 KW (3xREACT2-BATT)
Discharge power
REACT2-3.6-TL-OUTD
2 kW (1xREACT2-BATT),
3.6 kW (2xREACT2-BATT),
3.6 kW (3xREACT2-BATT)
REACT2-5.0-TL-OUTD
2 kW (1xREACT2-BATT),
4 kW (2xREACT2-BATT),
5 kW (3xREACT2-BATT)
Environmental
Environmental protection rating IP54 (suggested indoor installation for preserving battery life time)
Ambient temperature range -20...+55°C (out of 0...+40°C temperature range, battery will be disabled)
Suggested ambient temperature +5...+30°C
Storage temperature
-20...+25°C (6 months) or -20...+45°C (3 months)
Relative humidity 4…100 % condensing
Physical
Cooling Natural
Dimension (H x W x D) 740 mm x 490 mm x 229 mm
Weight 50 kg
Mounting system Wall bracket
Safety
Protective class I
Marking CE
Safety IEC 62619, UN38.3, UN3480
Energy meter
REACT-MTR-1PH Single-phase, 20A
ABB B21-212 Single-phase, 65A
ABB B23-212 Three-phase, 65A
ABB B24-212 Three-phase with external CT (opt.)
1) Refer to the document “String inverter – Product Manual appendix” available at www.abb.com/ solarinverters to know the brand
DQGWKHPRGHORIWKHTXLFN¿WFRQQHFWRU´
2) For VDE-AR-N 4105 setting, maximum active power of 4600 W and maximum apparent power of 4600 VA
7KH$&YROWDJHUDQJHPD\YDU\GHSHQGLQJRQVSHFL¿FFRXQWU\JULGVWDQGDUG
7KH)UHTXHQF\UDQJHPD\YDU\GHSHQGLQJRQVSHFL¿FFRXQWU\JULGVWDQGDUG
5) As per IEEE 802.11 b/g/n standard
6) In the event of a fault, limited by the external protection envisaged on the AC circuit
5HPDUN)HDWXUHVQRWVSHFL¿FDOO\OLVWHGLQWKHSUHVHQWGDWDVKHHWDUHQRWLQFOXGHGLQWKHSURGXFW
