- 63 -
000897AG
5 - Installation
 Lift the REACT2-BATT up to the
bracket and insert the heads of
two anchor points (present on
the back of the battery unit) into
the slots
on the bracket
20
.
Risk of injury due to
the heavy weight of
the equipment.
Hang up the lower part of the
REACT2-BATT to the wall using
the two anchor points
26
(holes
diameter 11 mm).
