Frequency Protection
Underfrequency, Overfrequency, Frequency rate of change, Source 1, Stage 1 FRPFRQ1 f</f>,df/dt(1) 81-1
Underfrequency, Overfrequency, Frequency rate of change, Source 1, Stage 2 FRPFRQ2 f</f>,df/dt(2) 81-2
Load Shed & Restoration, Source 1, Stage 1 LSHDPFRQ1 UFLS/R(1) 81S-1
Load Shed & Restoration, Source 1, Stage 2 LSHDPFRQ2 UFLS/R(2) 81S-2
Other Protection
High Impedance Fault Detector PHIZ1 PHIZ1 HIZ
Circuit breaker failure protection SCCBRBRF1 3I>/Io>BF 50BFT
Circuit breaker close failure protection SCCBRBCF1 SCCBRBCF1 50BFC
Directional positive sequence power protection DPSRDIR1 P>-> 32P
Directional negative/zero sequence power protection DNZSRDIR1 Q>-> 32N
Control
Autoreclosing, 1ph and/or 3ph SDARREC1 O -> I 79
Synch-check/voltage check (Source 1 is defined as bus, Source 2 as line)
SECRSYN1 SYNC 25
Circuit Breaker 1 (3 state inputs / 3 control outputs) SCBXCBR1 I<->O CB 52
Loop control DLCM LCM LCM
Supervision and Monitoring
CB condition monitoring SPSCBR1 CBCM 52CM
Fuse failure supervision, Source 1 SEQRFUF1 FUSEF 60
Measurement
Three-phase current CMMXU1 3I IA,IB,IC
Demand metering, Max/Min metering CMSTA1
Sequence current CSMSQI1 I1,I2,I0 I1, I2, I0
Ground current RESCMMXU1 Io IG
Three-phase voltage, Source 1 VMMXU1 3U VA,VB,VC
Three-phase voltage, Source 2 VMMXU2 3U(B) VA,VB,VC(2)
Sequence voltages, Source 1 VSMSQI1 U1,U2,U0 V1,V2,V0
Sequence voltages, Source 2 VSMSQI2 U1,U2,U0(B) V1,V2,V0(2)
Single and Three-phase power, Power factor and three phase energy, Source 1 APEMMXU1 P,SP,E P,SP,E
Frequency, Source 1 FMMXU1 f f
Recorders
Digital fault recorder (DFR) RDRE DR DFR
Sequence of Events (SER) SER SER SER
Fault Recorder FLTMSTA FLTMSTA FLTMSTA
Fault Locator (FLOC) DRFLO1 FLO FLO
Other Functions
Battery voltage, current. Test the battery ZBAT1 UPS UPS
Universal Power Drive XGGIO115 X115(UPD) X115(UPD)
Programmable buttons (16 buttons) FKEYGGIO1 FKEYGGIO1 FKEYGGIO1
Move function block (8 outputs) MVGAPC1 MVGAPC1 MVGAPC1
Move function block (8 outputs) MVGAPC2 MVGAPC2 MVGAPC2
Function IEC61850 IEC60617 ANSI/C37.2
