ABB RER620

Section 1 1MAC309294-MB F
Introduction
24 RER620
Technical Manual
Pulse timer (8 timers) PTGAPC1 PTGAPC1 PTGAPC1
Pulse timer (8 timers) PTGAPC2 PTGAPC2 PTGAPC2
Generic control points (16 outputs) SPCGGIO1 SPCGGIO1 SPCGGIO1
Generic control points (16 outputs) SPCGGIO2 SPCGGIO2 SPCGGIO2
Set reset flip flops (8 outputs) SRGAPC1 SRGAPC1 SRGAPC1
Set reset flip flops (8 outputs) SRGAPC2 SRGAPC2 SRGAPC2
Time delay off timers (8 timers) TOFGAPC1 TOFGAPC1 TOFGAPC1
Time delay off timers (8 timers) TOFGAPC2 TOFGAPC2 TOFGAPC2
Time delay on timers (8 timers) TONGAPC1 TONGAPC1 TONGAPC1
Time delay on timers (8 timers) TONGAPC2 TONGAPC2 TONGAPC2
Multipurpose generic up-down counter UDFCNT1 UDFCNT1 UDFCNT1
Multipurpose generic up-down counter UDFCNT2 UDFCNT2 UDFCNT2
Multipurpose generic up-down counter UDFCNT3 UDFCNT3 UDFCNT3
Multipurpose generic up-down counter UDFCNT4 UDFCNT4 UDFCNT4
Multipurpose generic up-down counter UDFCNT5 UDFCNT5 UDFCNT5
Multipurpose generic up-down counter UDFCNT6 UDFCNT6 UDFCNT6
Multipurpose generic up-down counter UDFCNT7 UDFCNT7 UDFCNT7
Multipurpose generic up-down counter UDFCNT8 UDFCNT8 UDFCNT8
Multipurpose generic up-down counter UDFCNT9 UDFCNT9 UDFCNT9
Multipurpose generic up-down counter UDFCNT10 UDFCNT10 UDFCNT10
Multipurpose generic up-down counter UDFCNT11 UDFCNT11 UDFCNT11
Multipurpose generic up-down counter UDFCNT12 UDFCNT12 UDFCNT12
Function IEC61850 IEC60617 ANSI/C37.2
