PICKUP_5B Binary 0=False AR start / pickup signal, input 5, phase B
PICKUP_5C Binary 0=False AR start / pickup signal, input 5, phase C
TRIP_6A Binary 0=False AR initialization / trip signal, input 6, phase A
TRIP_6B Binary 0=False AR initialization / trip signal, input 6, phase B
TRIP_6C Binary 0=False AR initialization / trip signal, input 6, phase C
TRIP_6_3P Binary 0=False AR initialization / trip signal, input 6, three phase
TRIP_6N Binary 0=False AR initialization / trip signal, input 6, neutral
PICKUP_6A Binary 0=False AR start / pickup signal, input 6, phase A
PICKUP_6B Binary 0=False AR start / pickup signal, input 6, phase B
PICKUP_6C Binary 0=False AR start / pickup signal, input 6, phase C
CB_POS_A Binary 0=False Circuit breaker position signal, phase A
CB_POS_B Binary 0=False Circuit breaker position signal, phase B
CB_POS_C Binary 0=False Circuit breaker position signal, phase C
CB_POS_3P Binary 0=False Circuit breaker position signal, three phase
BLK_RECL_T Binary 0=False Blocks and resets reclose time
BLK_RCLM_T Binary 0=False Blocks and resets reclaim time
BLK_THERM Binary 0=False Blocking signal from thermal overload protection
INC_SHOTP Binary 0=False Sequence control signal
INHIBIT_RECL Binary 0=False Interrupts and inhibits reclosing sequence
RECL_ON Binary 0=False Level sensitive signal for allowing (high) / not allowing reclosing
SYNC Binary 0=False Synch-check signal
Name Type Default Description
