Section 5 1MAC309294-MB F
Control functions
316 RER620
Technical Manual
Table 298: 79 output signals
Name Type Description
OPEN_CB_A Binary Open command to Circuit Breaker, phase A
CLOSE_CB_A Binary (Re)close command to Circuit Breaker, phase A
LOCKED_A Binary Locked out, phase A
OPEN_CB_B Binary Open command to Circuit Breaker, phase B
CLOSE_CB_B Binary (Re)close command to Circuit Breaker, phase B
LOCKED_B Binary Locked out, phase B
OPEN_CB_C Binary Open command to Circuit Breaker, phase C
CLOSE_CB_C Binary (Re)close command to Circuit Breaker, phase C
LOCKED_C Binary Locked out, phase C
OPEN_CB_3P Binary Open command to Circuit Breaker, three phase
CLOSE_CB_3P Binary (Re)close command to Circuit Breaker, three phase
LOCKED_3P Binary Locked out, three phase
CMD_WAIT Binary Wait for master command
INPRO Binary Reclosing shot in progress, activated during reclose time
PROT_CRD Binary Protection coordination signal
UNSUC_RECL Binary reclosing sequence unsuccessful
AR_ON Binary status ON / OFF
READY Binary ready for new sequence
