Synchronization set 0...127 0 Configures synchrony check for CBB
Auto wait time 0.00...60.00 s 0.01 2.00 Maximum wait time for reclosing condition fulfilling
Auto lockout reset 0=False
1=True
1=True Automatic lockout reset
Protection crd limit 1...5 3 Protection coordination shot limit
Protection crd mode 1=No condition
2=AR
inoperative
3=CB close
manual
4=AR inop, CB
man
5=Always
1=No condition Protection coordination mode
Auto initiation cnd 1=Not allowed
2=When sync
fails
3=CB
doesn't
close
4=Both
2=When sync
fails
Auto initiation condition
Tripping line 0...63 63 Defines INIT inputs which cause CMD_OPEN activation
Control line 0...63 63 Defines INIT inputs which are protection signals
Allow shot jump 0=False
1=True
1=True Allows shot jumping
CB closed Pos status 0=False
1=True
1=False Status (TRUE or FALSE) meaning closed CB in input
CB_POS
Fourth delay in SOTF 0=False
1=True
0=False Sets fourth delay into use for all DEL_INIT signals during
SOTF
Init signals CBB1 0...63 3 Sets INIT inputs which initiate CBB1
Init signals CBB2 0...63 3 Sets INIT inputs which initiate CBB2
Init signals CBB3 0...63 3 Sets INIT inputs which initiate CBB3
Init signals CBB4 0...63 3 Sets INIT inputs which initiate CBB4
Init signals CBB5 0...63 0 Sets INIT inputs which initiate CBB5
Init signals CBB6 0...63 0 Sets INIT inputs which initiate CBB6
Init signals CBB7 0...63 0 Sets INIT inputs which initiate CBB7
Blk signals CBB1 0...63 60 Sets INIT inputs which block CBB1
Blk signals CBB2 0...63 60 Sets INIT inputs which block CBB2
Blk signals CBB3 0...63 60 Sets INIT inputs which block CBB3
Blk signals CBB4 0...63 60 Sets INIT inputs which block CBB4
Blk signals CBB5 0...63 0 Sets INIT inputs which block CBB5
Blk signals CBB6 0...63 0 Sets INIT inputs which block CBB6
Blk signals CBB7 0...63 0 Sets INIT inputs which block CBB7
Shot number CBB1 0...5 0 Sets CBB1 shot number
Shot number CBB2 0...5 0 Sets CBB2 shot number
Shot number CBB3 0...5 0 Sets CBB3 shot number
Shot number CBB4 0...5 0 Sets CBB4 shot number
Shot number CBB5 0...5 0 Sets CBB5 shot number
Shot number CBB6 0...5 0 Sets CBB6 shot number
Parameter Values (Range) Unit Step Default Description
