ABB RER620

1MAC309294-MB F Section 5
Control functions
RER620 321
Technical Manual
Table 301: SDAOGGIO monitored inputs
TRIPOUT_5 Binary 0=False
1=True
Protection trip active for input 5
ACTIVE_6A Binary 0=False
1=True
Phase A protection active for input 6
ACTIVE_6B Binary 0=False
1=True
Phase B protection active for input 6
ACTIVE_6C Binary 0=False
1=True
Phase C protection active for input 6
ACTIVE_6_3P Binary 0=False
1=True
Three phase protection active for input 6
TRIPOUT_6 Binary 0=False
1=True
Protection trip active for input 6
Name Type Values (Range) Unit Description
ACTIVE_PH_A Binary 0=False
1=True
Phase A protection is active for trip
ACTIVE_PH_B Binary 0=False
1=True
Phase B protection is active for trip
ACTIVE_PH_C Binary 0=False
1=True
Phase C protection is active for trip
ACTIVE_PH_3P Binary 0=False
1=True
Three phase protection is active for trip
RECLOSE_IN Binary 0=False
1=True
Reclose command active
OPEN_IN Binary 0=False
1=True
Open command active
LOCKOUT_IN Binary 0=False
1=True
Lockout command active
INPROGRESS_IN Binary 0=False
1=True
Reclose sequence in progress
CB_POS_A Circuit breaker position signal, phase A
CB_POS_B Circuit breaker position signal, phase B
CB_POS_C Circuit breaker position signal, phaseC
CB_POS_P Circuit breaker position signal, three phase
Name Type Values (Range) Unit Description
