Table 302: 79 monitored data
Name Type Values (Range) Unit Description
FRQ_OPR_CNT INT32 0...2147483647 Frequent operation counter
FRQOP_CNT_AL Binary 0=False
1=True
Frequent operation counter alarm
STATUS Enum -2=Unsuccessful
-1=Not defined
1=Ready
2=In progress
3=Successful
Auto reclosing status
ACTIVE Binary 0=False
1=True
Reclosing sequence active
INPRO_1 Binary 0=False
1=True
First reclosing in progress
INPRO_2 Binary 0=False
1=True
Second reclosing in progress
INPRO_3 Binary 0=False
1=True
Third reclosing in progress
INPRO_4 Binary 0=False
1=True
Fourth reclosing in progress
INPRO_5 Binary 0=False
1=True
Fifth reclosing in progress
DISCR_IN_PRO Binary 0=False
1=True
Discrimination time in progress
CUTOUT_INPRO Binary 0=False
1=True
Cut-out time in progress
SUC_RECL Binary 0=False
1=True
Reclosing sequence successful
UNSUC_CB Binary 0=False
1=True
Circuit breaker closing unsuccessful
CNT_SHOT1 INT32 0...2147483647 Resetable operation counter, shot 1
CNT_SHOT2 INT32 0...2147483647 Resetable operation counter, shot 2
CNT_SHOT3 INT32 0...2147483647 Resetable operation counter, shot 3
CNT_SHOT4 INT32 0...2147483647 Resetable operation counter, shot 4
CNT_SHOT5 INT32 0...2147483647 Resetable operation counter, shot 5
COUNTER INT32 0...2147483647 Resetable operation counter, all shots
SHOT_PTR INT32 0...6 Shot pointer value
MAN_CB_CL Binary 0=False
1=True
Circuit breaker closed manually
SOTF Binary 0=False
1=True
Switch-onto-fault
REC_T_STD Binary 0=False
1=True
Reclaim time started
REC_T_ELA Binary 0=False
1=True
Reclaim time elapsed
DISA_COUNT Disable signal for counters
