Section 3 1MAC309294-MB F
Basic functions
34 RER620
Technical Manual
Table 11: Binary input: Non group settings
Table 12: Ethernet front port: Non group settings
Table 13: Ethernet rear port: Non group settings
Table 14: General system: Non group settings
Parameter Values (Range) Unit Step Default Description
Threshold voltage 18...176 Vdc 2 48 Digital input threshold voltage
Input osc. level 2...50 events/s 1 30 Digital input oscillation suppression threshold
Input osc. hyst 2...50 events/s 1 10 Digital input oscillation suppression hysteresis
Parameter Values (Range) Unit Step Default Description
IP address 192.168.0.254 IP address for front port (fixed)
Mac address XX-XX-XX-XX-XX-XX Mac address for front port
Parameter Values (Range) Unit Step Default Description
IP address 192.168.2.10 IP address for rear port(s)
Subnet mask 255.255.255.0 Subnet mask for rear port(s)
Default gateway 192.168.2.1 Default gateway for rear port(s)
Mac address XX-XX-XX-XX-XX-XX Mac address for rear port(s)
Parameter Values (Range) Unit Step Default Description
Rated frequency 1=50Hz
2=60Hz
2=60Hz Rated frequency of the network
Phase rotation 1=ABC
2=ACB
1=ABC Phase rotation order
Blocking mode 1=Freeze timer
2=Block all
3=Block trip
1=Freeze timer Behavior for function BLOCK inputs
Bay name RER620 Bay name in system
SG follow input 0=False
1=True
0=False Enable setting group change to follow the input state
Phase Order Mode 1=ABC
2=BCA
3=CAB
4=ACB
5=CBA
6=BAC
1=ABC Selection for phase correction order
When the Phase Order Mode setting is changed, the relay must be rebooted
to activate the new setting.
