Table 15: HMI: Non group settings
Table 16: IEC 61850-8-1 MMS: Non group settings
Parameter Values (Range) Unit Step Default Description
FB naming convention 1=IEC61850
2=IEC60617
4=ANSI
4=ANSI FB naming convention used in relay
Default view 1=Measurements
2=Main menu
1=Measurements LHMI default view
Backlight timeout 1...60 min 1 60 LHMI backlight timeout
Web HMI mode 1=Active read only
2=Active
3=Disabled
2=Active Web HMI functionality
Web HMI timeout 1...60 min 1 10 Web HMI login timeout
SLD symbol format 1=IEC
2=ANSI
2=ANSI Single Line Diagram symbol format
Parameter Values (Range) Unit Step Default Description
Unit mode 1=Primary
0=Nominal
2=Primary-Nominal
0=Nominal IEC 61850-8-1 unit mode
