Table 17: DNP3: Non group settings
Parameter Values (Range) Unit Step Default Description
DNP physical layer 1=Serial
2=TCP/IP
3=Both
2=TCP/IP DNP physical layer
Unit address 1...65519 1 1 DNP unit address
Master address 1...65519 1 3 DNP master and UR address
Serial port 0=Not in use
1=COM 1
2=COM 2
0=Not in use COM port for serial interface, when physical layer is serial.
Need time interval 0...65535 min 1 30 Period to set IIN need time bit
Time format 0=UTC
1=Local
1=Local UTC or local. Coordinate with master.
CROB select timeout 1...65535 sec 1 10 Control Relay Output Block select timeout
Data link confirm 0=Never
1=Only Multiframe
2=Always
0=Never Data link confirm mode
Data link confirm TO 100...65535 ms 1 3000 Data link confirm timeout
Data link retries 0...65535 1 3 Data link retries count
Data link Rx to Tx delay 0...255 ms 1 0 Turnaround transmission delay
Data link inter char delay 0...20 char 1 4 Inter character delay for incoming messages
App layer confirm 1=Disable
2=Enable
1=Disable Application layer confirm mode
App confirm TO 100...65535 ms 1 5000 Application layer confirm and UR timeout
App layer fragment 256...2048 bytes 1 2048 Application layer fragment size
UR mode 1=Disable
2=Enable
1=Disable Unsolicited responses mode
UR retries 0...65535 1 3 Unsolicited retries before switching to UR offline mode
UR TO 0...65535 ms 1 5000 Unsolicited response timeout
UR offline interval 0...65535 min 1 15 Unsolicited offline interval
UR Class 1 Min events 0...999 1 2 Min number of class 1 events to generate UR
UR Class 1 TO 0...65535 ms 1 50 Max holding time for class 1 events to generate UR
UR Class 2 Min events 0...999 1 2 Min number of class 2 events to generate UR
UR Class 2 TO 0...65535 ms 1 50 Max holding time for class 2 events to generate UR
UR Class 3 Min events 0...999 1 2 Min number of class 3 events to generate UR
UR Class 3 TO 0...65535 ms 1 50 Max holding time for class 3 events to generate UR
Legacy master UR 1=Disable
2=Enable
1=Disable Legacy DNP master unsolicited mode support. When
enabled relay does not send initial unsolicited message.
Legacy master SBO 1=Disable
2=Enable
1=Disable Legacy DNP Master SBO sequence number relax enable
Default Var Obj 01 1...2 1 1 1=BI; 2=BI with status.
Default Var Obj 02 1...2 1 2 1=BI event; 2=BI event with time.
Default Var Obj 30 1...4 1 2 1=32 bit AI; 2=16 bit AI; 3=32 bit AI without flag; 4=16 bit AI
without flag.
Default Var Obj 32 1...4 1 4 1=32 bit AI event; 2=16 bit AI event; 3=32 bit AI event with
time; 4=16 bit AI event with time.
