ABB RER620

Section 3 1MAC309294-MB F
Basic functions
44 RER620
Technical Manual
Table 27: X110 BIO: Non group settings
Table 28: X120 AIM: Input signals
Table 29: X120 AIM: Non group settings
Parameter Values (Range) Unit Step Default Description
Input 1 filter time 5...1000 ms 5 Connectors 1-2
Input 2 filter time 5...1000 ms 5 Connectors 3-4
Input 3 filter time 5...1000 ms 5 Connectors 5-6c
Input 4 filter time 5...1000 ms 5 Connectors 7-6c
Input 5 filter time 5...1000 ms 5 Connectors 8-9c
Input 6 filter time 5...1000 ms 5 Connectors 10-9c
Input 7 filter time 5...1000 ms 5 Connectors 11-12c
Input 8 filter time 5...1000 ms 5 Connectors 13-12c
Input 1 inversion 0=False
1=True
0=False Connectors 1-2
Input 2 inversion 0=False
1=True
0=False Connectors 3-4
Input 3 inversion 0=False
1=True
0=False Connectors 5-6c
Input 4 inversion 0=False
1=True
0=False Connectors 7-6c
Input 5 inversion 0=False
1=True
0=False Connectors 8-9c
Input 6 inversion 0=False
1=True
0=False Connectors 10-9c
Input 7 inversion 0=False
1=True
0=False Connectors 11-12c
Input 8 inversion 0=False
1=True
0=False Connectors 13-12c
Name Type Description
X120-Input 1 BOOLEAN Connectors 1-2c
X120-Input 2 BOOLEAN Connectors 3-2c
X120-Input 3 BOOLEAN Connectors 4-2c
X120-Input 4 BOOLEAN Connectors 5-6
Parameter Values (Range) Unit Step Default Description
Input 1 filter time 5...1000 ms 5 Connectors 1-2c
Input 2 filter time 5...1000 ms 5 Connectors 3-2c
Input 3 filter time 5...1000 ms 5 Connectors 4-2c
Input 4 filter time 5...1000 ms 5 Connectors 5-6
Input 1 inversion 0=False
1=True
0=False Connectors 1-2c
Input 2 inversion 0=False
1=True
0=False Connectors 3-2c
Input 3 inversion 0=False
1=True
0=False Connectors 4-2c
Input 4 inversion 0=False
1=True
0=False Connectors 5-6
