1MAC309294-MB F Section 3
Basic functions
RER620 43
Technical Manual
Table 24: X100 PSM: Output signals
Table 25: X110 BIO: Output signals
Table 26: X110 BIO: Input signals
Name Type Default Description
X100-PO1 BOOLEAN 0=False Connectors 6-7
X100-PO2 BOOLEAN 0=False Connectors 8-9
X100-SO1 BOOLEAN 0=False Connectors 10c-11nc-12no
X100-SO2 BOOLEAN 0=False Connectors 13c-14no
X100-PO3 BOOLEAN 0=False Connectors 15-17/18-19
X100-PO4 BOOLEAN 0=False Connectors 20-22/23-24
Name Type Default Description
X110-SO1 BOOLEAN 0=False Connectors 14c-15no-16nc
X110-SO2 BOOLEAN 0=False Connectors 17c-18no-19nc
X110-SO3 BOOLEAN 0=False Connectors 20c-21no-22nc
X110-SO4 BOOLEAN 0=False Connectors 23-24
Name Type Description
X110-Input 1 BOOLEAN Connectors 1-2
X110-Input 2 BOOLEAN Connectors 3-4
X110-Input 3 BOOLEAN Connectors 5-6c
X110-Input 4 BOOLEAN Connectors 7-6c
X110-Input 5 BOOLEAN Connectors 8-9c
X110-Input 6 BOOLEAN Connectors 10-9c
X110-Input 7 BOOLEAN Connectors 11-12c
X110-Input 8 BOOLEAN Connectors 13-12c
