Section 16 Fault tracing and repair
About this chapter
This chapter describes how to carry out fault tracing and if necessary, a change of
circuit board.
16.1
Fault tracing
16.1.1 Information on the local HMI
If an internal fault has occurred, the local HMI displays information under Main
menu/Diagnostics/IED status/General
Under the Diagnostics menus, indications of a possible internal failure (serious
fault) or internal warning (minor problem) are listed.
Indications regarding the faulty unit are outlined in table
27.
Table 27: Self-supervision signals on the local HMI
HMI Signal Name: Status Description
INT Fail OFF / ON This signal will be active if one or more
of the following internal signals are
active; INT--NUMFAIL, INT--
LMDERROR, INT--WATCHDOG, INT--
APPERROR, INT--RTEERROR, INT--
FTFERROR, or any of the HW
dependent signals
INT Warning OFF / ON This signal will be active if one or more
of the following internal signals are
active; INT--RTCERROR, INT--
IEC61850ERROR, INT--
TIMESYNCHERROR
NUM Fail OFF / ON This signal will be active if one or more
of the following internal signals are
active; INT--WATCHDOG, INT--
APPERROR, INT--RTEERROR, INT--
FTFERROR
NUM Warning OFF / ON This signal will be active if one or more
of the following internal signals are
active; INT--RTCERROR, INT--
IEC61850ERROR
ADMnn READY / FAIL Analog input module n failed. Signal
activation will reset the IED
BIMnn READY / FAIL BIM error. Binary input module Error
status.
Signal activation will reset the IED
Table continues on next page
1MRK 504 088-UEN C Section 16
Fault tracing and repair
219
Installation and commissioning manual
